When maintenance and repair work is being done, a mechanical switch called an offload isolator is used to reliably disconnect a circuit and remove current from it. These switches are used to create safe maintenance and repair workplaces in many commercial and industrial units as well as distribution and EHV transmission substations.
As Balaji Engineers is one of the leading off load disconnector isolator manufacturers in India, we like share 10 facts about electrical isolators with you.
1) Electrical offload isolators disconectors are only used when there is no load: Electrical isolators are used to open a circuit when there is no load. This means that it can only be used when the current flowing through it is zero.
2) Electrical isolators are different circuit breakers: A circuit breaker is an on-load device, whereas an isolator is an off-load device. A circuit breaker detects and trips when an electric fault occurs. Offload Electrical isolators must be manually operated.
3) High voltage equipment requires offload isolators: when high voltage equipment is turned on, it can cause electrical accidents. Offload isolator switches are required for such equipment. 11kv,22kv,33kv in H T Consumer Isolator switches were required in industrial units before the metering cubical and also in the Transformer feeder bay. Off load isolators are used in solar substations, generation infrastructure, and line isolation.
a. Double Break Offload Isolator
b. Single Break Offload Isolator
c. Pantograph type Offload Isolator
5) Operation of Offload Isolator : Isolators can be operated by either type. 1) manually (mechanical type) 2) motorised type. Both arrangements are provided in the fabrication structure at the bottom of the Off load isolator structure.
6) Isolators are further divided in to With earth switch and without earth switch , For With earth switch disconnector switch having earthing arrangement of Copper Male moving contact and female fixed earth contact . It is used all over considering safety factor while operating of electrical system.
7) Commonly used Isolators : Mainly isolator is design is depend upon a mechanism which fix the male copper contact in to female copper contact firmly and unlock easy when it is required . Horizontal Banging type Isolator disconnector and Turn and twist type Isolator disconnectors are very unique in its operations.
8) Earthing to Isolator – Considering electrical safety , Isolator disconnect equipment is earthed by GI or Copper strip to a Earthing electrode.
Isolators Disconnectors are Mounted civil structure design provided by Isolator manufacturer. Isolator is mounted on foundation bolts provided by Isolator manufacturer
10) Isolator disconnecting switch Standard of Manufacturing : Isolator manufacturing is done as per IEC 62271-102 Amended up to date .
Balaji Engineers is a leading Isolator Manufacturing company in India, our products and used in almost all states utilities, Power generation station, Distribution Substation, Transmission substation, Solar substation, E V Charging substation and in Distribution networks. Our isolators are 11kv, 22kv, 33 kv manufacturing as per IEC 62271-102. Our products are type tested by NABL Lab CPRI ERDA etc.
